700Bar Stainless Steel Pressure Transmitter IP65 YW-130 Aviation Plug-In Pressure Transmitter

Name: 700Bar Stainless Steel Pressure Transmitter IP65 YW130 Aviation PlugIn Pressure Transmitter
Brand: XINYI
Price: 1 USD

700Bar Stainless Steel Pressure Transmitter IP65 YW-130 Aviation Plug-In Pressure Transmitter Manufactures

Brand Name : XINYI

Model Number : YW-130

Certification : CE

Place of Origin : China

MOQ : 1

Payment Terms : L/C,D/A,D/P,T/T,Western Union,MoneyGram

Supply Ability : 1000 pcs/Month

Delivery Time : 5 work days

Packaging Details : carton

Name : Stainless Steel Pressure Transmitter

Range : -100~700kPa~70MPa

Pressure type : Gauge pressure/Absolute pressure/Seal pressure

Output signal : 4-20mA、0~5V、0.5~4.5V

Power supply : 9-24 VDC

Accuracy class : 0.5%FS/0.2%FS

Compensation temperature : -10~70℃

working temperature : -20~80℃

Protection level : IP65

Contact Now

700Bar Stainless Steel YW-130 Aviation Plug-In Pressure Transmitter

The aviation plug-in pressure transmitter uses a pressure sensor with a stainless steel isolation membrane as the signal measurement element, and has been automatically tested by a computer. The zero point and temperature performance compensation of a wide temperature range has been carried out using laser resistance adjustment technology. The signal processing circuit is located inside a stainless steel casing and converts sensor signals into standard output signals. The entire product has undergone rigorous testing and aging screening of components, semi-finished products, and finished products, with stable and reliable performance. This product is widely used for pressure measurement and control in industrial process sites such as petroleum, chemical, metallurgical, power, and hydrological industries due to its reliability, flexibility, and diversity.

All stainless steel structure;
Multiple structures to choose from;
Compact in size and easy to install;
Standard thread pressure measurement method;
Gauge pressure, absolute pressure, and sealed gauge pressure;
Laser resistance compensation zero point and temperature performance;
High reliability and stability;
The output signal forms are diverse;
Constant current source power supply;
Reverse polarity protection and instantaneous overcurrent and overvoltage protection comply with EMI protection requirements;

Product Name	Aviation plug-in pressure transmitter
Zero temperature drift	0.5%FS
Sensitivity temperature drift	0.5%FS
Pressure overload	2 times below 10MPa; 1.5 times above 25MPa
Mechanical vibration	20g
Sampling time	2400/S
Long term stability	≤0.2%FS/year
Isolation	100MΩ/250VDC
